سوییچ 8 پورت (S3300-10-PWR-M(F1210P آی پی کام

>سوییچ 8 پورت (S3300-10-PWR-M(F1210P آی پی کام
سوییچ 8 پورت (S3300-10-PWR-M(F1210P آی پی کام 2018-07-26T11:23:35+00:00

Project Description

سوییچ 8 پورت (S3300-10-PWR-M(F1210P

  • سوئیچ Web Smart

  • 8 پورت 10/100Mbps

  • ۲ پورت 10/100/1000Mbps

  • 8 پورت POE

  • استاندارد IEEE 802.3af/at

  • 2 پورت (SFP (combo

  • توان 125W

  • 3 سال گارانتی آونگ

IEEE 802.3、 IEEE 802.3u、IEEE 802.3z、IEEE 802.3ab、IEEE 802.3x、IEEE 802.1D、IEEE 802.1W、IEEE 802.1Q、IEEE 802.3af、IEEE 802.3atStandard and protocol supported
100,000hoursMTBF
Link/Act, PoE Status,System, Power,PoE MaxIndicator LEDs
8port 10/100Base-TX
2port 10/100/1000Base-T
(2port 1000Base-X SFP (Combo
Fixed Ports
6KV=<lightning protection
YesStore and forward
5.6Gbit/sExchange capacity
4K MACMAC address entries
(Providing 8 ports under IEEE 802.3af(15.4W) or 4 ports under IEEE 802.3at(30WPower supply module
1,2,4,5 +
3,6,7,8, -
PoE through pin
AC:100-240V~ 50/60HzVoltage input range
293mm*178.8mm*44mmDimension
5kg>=Weight
150>
WPoE consumption up to 130W
Total power consumption
0c-40cperating temperature
40c-70cStorage temperature
10%-95%
(noncondensing)
(Relative humidity(Operational
10%-95%
(noncondensing)
(Relative humidity(Storage
Software Feature
Support setup of PoE
Support power adjustable by priority
Support over temperature protection for PoE module
PoE management
Support VLAN(4K) based on ports
Support 802.1QVLAN
VLAN
Support local mirror image
Mirroring
Support LACP, manual link aggregation
Support up to 6 link aggregation groups and up to 8 GE ports per group
Link aggregation
Support message transmission for ports and limitation of speed
Support SP & WRR
QoS
Support STP/RSTP and looped Network for devices
Layer 2 ring network protocol
FCC/CE/RoHS
Certification
