| استانداردهای شبکه | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.3, IEEE 802.3u, IEEE 802.11i, IEEE 802.11e, IPv4, IPv6 |
|---|
| حافظه | 128MB NAND flash/256MB DDR3 |
|---|
| درگاه USB | USB 2.0 |
|---|
| سرعت Wi-Fi | AC750 تا AC1200 |
|---|
| تکنولوژی Wi-Fi | 802.11ac |
|---|
| برند | ASUS |
|---|
| مدیریت | Web-based GUI configuration
Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI
UPnP IGD 1.0
Auto VPI/VCI detection
Configuration backup and restore
Diagnostics
Log & Trace function |
|---|
| امنیت | 64bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK |
|---|
| توان خروجی | ac mode : 18 dBm
b mode : 20.5 dBm
g mode : 18.5 dBm
n mode : 17.5 dBm
a/n mode : 20 dBm |
|---|
| فرکانس های کاری | 2.4GHz
5GHz |
|---|
| سرعت انتقال اطلاعات بی سیم | 802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps |
|---|
| قابلیت های خاص روتر | 3G/4G data sharing, AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control |
|---|
| قابلیت های USB | Printer Server
FTP Server
Download Master
3G/4G sharing |
|---|
| پورتها | 1x RJ11 for xDSL
4x RJ45 10/100/Gigabits BaseT for LAN
1x RJ45 10/100/Gigabits BaseT for WAN
USB 2.0 x 2 |
|---|
| کلیدها | WPS Button, Reset Button, Power Button, Wireless on/off Button |
|---|
| نشانگر LED | Power, Internet, LAN x 1, xDSL, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi, USB x 1 |
|---|
| آنتن | 4 آنتن داخلی |
|---|
| ویژگی ها | DHCP server, firewall/NAT, DynDNS
(VPN server(PPTP/OpenVPN
(VPN client(PPTP/L2TP/OpenVPN
Dual WAN Fail over/Fail back/Load balance
(Traffic monitor/Quality of Service (QoS
DSL spectrum
(IPTV(VDSL/ADSL WAN
DSL feedback mechanism
Save/Restore configuration file
WiFi Bandwidth Limiter
AiProtection |
|---|
| سرعت انتقال اطلاعات xDLS | VDSL2/ADSL2+/ADSL2/ADSL multimode
Support Annex A/B/I/J/L/M
Support all VDSL2 profiles -8a, 8b, 8c, 8d, 12a, 12b, 17a and 30a
VDSL2 interface compliance with ITU-T G.993.2
ITU-T G.992.1 (G.dmt), Annex A, and B Compliant
ITU-T G.992.2 (G.lite), Annex A, and B Compliant
ANSI T1.413 Compliant
ITU-T G.992.3 (ADSL2) Compliant, Annex A, B, L, and M
ITU-T G.992.5 (ADSL2+) Compliant, Supporting Annex A, B, and M
ITU-T G.993.2 Compliant, Annex A, B
(TU-T G.993.5 (Vectoring
ITU-T G.998.4 (G.inp) Improved impulse noise protection
(ATM and PTM (dual-priority VDSL2 Upstream: 150Mbps, Downstream: 200Mbps
ADSL2+ Upstream: 3.3Mbps, Downstream: 24Mbps
ADSL2 Upstream: 3.5Mbps, Downstream: 12Mbps |
|---|
| استاندارد DSL | VDSL/ADSL |
|---|
