| استانداردهای شبکه |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.3, IEEE 802.3u, IEEE 802.11i, IEEE 802.11e, IPv4, IPv6
|
| فرکانس های کاری |
2.4GHz
5GHz
|
| درگاه USB |
USB 2.0
|
| سرعت Wi-Fi |
AC750 تا AC1200
|
| تکنولوژی Wi-Fi |
802.11ac
|
| برند |
ASUS
|
| مدیریت |
Web-based GUI configuration
Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI
UPnP IGD 1.0
Auto VPI/VCI detection
Configuration backup and restore
Diagnostics
Log & Trace function
|
| امنیت |
64bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK
|
| توان خروجی |
ac mode : 18 dBm
b mode : 20.5 dBm
g mode : 18.5 dBm
n mode : 17.5 dBm
a/n mode : 20 dBm
|
| حافظه |
128MB NAND flash/256MB DDR3
|
| قابلیت های خاص روتر |
3G/4G data sharing, AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control
|
| سرعت انتقال اطلاعات بی سیم |
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
|
| قابلیت های USB |
Printer Server
FTP Server
Download Master
3G/4G sharing
|
| پورتها |
1x RJ11 for xDSL
4x RJ45 10/100/Gigabits BaseT for LAN
1x RJ45 10/100/Gigabits BaseT for WAN
USB 2.0 x 2
|
| کلیدها |
WPS Button, Reset Button, Power Button, Wireless on/off Button
|
| نشانگر LED |
Power, Internet, LAN x 1, xDSL, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi, USB x 1
|
| آنتن |
4 آنتن داخلی
|
| ویژگی ها |
DHCP server, firewall/NAT, DynDNS
(VPN server(PPTP/OpenVPN
(VPN client(PPTP/L2TP/OpenVPN
Dual WAN Fail over/Fail back/Load balance
(Traffic monitor/Quality of Service (QoS
DSL spectrum
(IPTV(VDSL/ADSL WAN
DSL feedback mechanism
Save/Restore configuration file
WiFi Bandwidth Limiter
AiProtection
|
| سرعت انتقال اطلاعات xDLS |
VDSL2/ADSL2+/ADSL2/ADSL multimode
Support Annex A/B/I/J/L/M
Support all VDSL2 profiles -8a, 8b, 8c, 8d, 12a, 12b, 17a and 30a
VDSL2 interface compliance with ITU-T G.993.2
ITU-T G.992.1 (G.dmt), Annex A, and B Compliant
ITU-T G.992.2 (G.lite), Annex A, and B Compliant
ANSI T1.413 Compliant
ITU-T G.992.3 (ADSL2) Compliant, Annex A, B, L, and M
ITU-T G.992.5 (ADSL2+) Compliant, Supporting Annex A, B, and M
ITU-T G.993.2 Compliant, Annex A, B
(TU-T G.993.5 (Vectoring
ITU-T G.998.4 (G.inp) Improved impulse noise protection
(ATM and PTM (dual-priority
VDSL2 Upstream: 150Mbps, Downstream: 200Mbps
ADSL2+ Upstream: 3.3Mbps, Downstream: 24Mbps
ADSL2 Upstream: 3.5Mbps, Downstream: 12Mbps
|
| استاندارد DSL |
VDSL/ADSL
|
