| رابط های کاربری |
48 پورت گیگابیتی شبکه
4 پورت +10G SFP
|
| استانداردها و ویژگی های پورت |
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3x Flow Control for full-duplex mode, auto-negotiation
|
| ویژگی های لایه 3 ای |
: ARP
256Static ARP
Supports Gratuitous ARP
(IPv6 Neighbour Discovery (ND
Default Routing
:Static Routing
64IPv4 Static Route Entries
32IPv6 Static Route Entries
|
| QoS |
<strong>CoS based on</strong>
Switch Port
802.1p Priority
VLAN ID
MAC Address
Ether Type
IPv4/IPv6 address
DSCP
ToS
Protocol Type
TCP/UDP Port
IPv6 Traffic Class
IPv6 Flow Label
User Defined Packet Content
<strong>Bandwidth Control</strong>
(Port-based (Ingress, Min. Granularity 64 Kbps
(Flow-based (Ingress, Min. Granularity 64 Kbps
(Egress queue bandwidth control (Min. Granularity 64 Kbps
<strong>Queue Handling</strong>
(Strict Priority Queue (SPQ
(Weighted Round Robin (WRR
SPQ + WRR
<strong>8queues per port</strong>
|
| امنیت |
SSH v1/v2
SSL v1/v2/v3
Port Security
Broadcast/Multicast/Unicast Storm Control
(IP-MAC-Port Binding (IMPB)
Traffic Segmentation
D-Link Safeguard Engine
L3 Control Packet Filtering
NetBIOS/NetBEUI Filtering
DHCP Server Screening
DHCP Client Filtering
ARP Spoofing Prevention
BPDU Attack Protection
DoS Attack Prevention
|
| OAM |
Cable Diagnostics
802.3ah Ethernet Link OAM
Dying Gasp
(802.1ag Connectivity Fault Management (CFM)
|
| مدیریت |
(Web-based GUI (Supports IPv4/v6
(Command Line Interface (CLI
(Telnet Server/Client (Supports IPv4
(TFTP/FTP Client (Supports IPv4
ZModem
Command Logging
( SNMP v1/v2c/v3 (Supports IPv4
SNMP Traps
System Log
( SMTP (IPv4
802.1AB LLDP
LLDP-MED
(BootP/DHCP Client (Supports IPv4
DHCP Auto-Configuration1
(DHCP Relay (Supports IPv4
DHCP Relay Option 60, 61 and 82
DHCP Client Option 12
PPPoE Circuit-ID Tag Insertion
Multiple Image
Flash File System
CPU Monitoring
Memory Monitoring
(SNTP (Supports IPv4
Debug Command
Password Recovery
Password Encryption
Ping
Traceroute
(Microsoft® NLB (Network Load Balancing) Support (Supports IPv4
(Zero Touch Provisioning (ZTP
sFlow1
D-Link Network Assistant1
|
| رابط کاربری |
48 پورت گیگابیتی شبکه
4 پورت +10G SFP
|
| سایز جدول MAC Address |
Up to 16,384 entries per device
|
| L2 Multicasting |
<strong>IGMP Snooping</strong>
IGMP v1/v2 Snooping, v3 awareness
Supports 1024 groups
Port/Host-based IGMP Snooping Fast Leave
Report Suppression
IGMP Authentication
(Limited IP Multicast (IGMP Filtering
<strong>MLD Snooping</strong>
MLD v1, MLD v2 awareness
Supports 1024 groups
Port/Host-based MLD snooping Fast Leave
|
| (Quality of Service (QoS |
<strong>CoS based on</strong>
Switch Port
802.1p Priority
VLAN ID
MAC Address
Ether Type
IPv4/IPv6 address
DSCP
ToS
Protocol Type
TCP/UDP Port
IPv6 Traffic Class
IPv6 Flow Label
User Defined Packet Content
<strong>Bandwidth Control</strong>
(Port-based (Ingress, Min. Granularity 64 Kbps
(Flow-based (Ingress, Min. Granularity 64 Kbps
(Egress queue bandwidth control (Min. Granularity 64 Kbps
<strong>Queue Handling</strong>
(Strict Priority Queue (SPQ
(Weighted Round Robin (WRR
SPQ + WRR
<strong>8queues per port</strong>
|
| برند |
D-link
|
| محل استفاده |
Rackmount
|
| تعداد پورت |
48 پورت و بالاتر
|
| PoE |
802.11af, 802.11at
|
| نوع پورت |
Gigabit Ethernet
|
| نوع پورت آپلینک |
SFP 10 Gigabit
|
| VLAN |
<strong>VLAN Group</strong>
Max. 4094 VLAN
<strong>Port-based VLAN</strong>
<strong>MAC-based VLAN</strong>
<strong>GVRP</strong>
Max. 255 dynamic VLANs
<strong>802.1v Protocol VLAN</strong>
<strong>802.1Q Tagged VLAN</strong>
<strong>(Double VLAN (Q-in-Q</strong>
Port-based Q-in-Q
<strong>ISM VLAN</strong>
<strong>VLAN Translation</strong>
<strong>VLAN Trunking</strong>
|
| ویژگی های لایه 2 ای |
<strong>Flow Control</strong>
802.3x Flow Control
HOL Blocking Prevention
<strong> Jumbo Frames up to 9216 Bytes</strong>
<strong>Spanning Tree Protocols</strong>
802.1D STP
802.1w RSTP
802.1s MSTP
<strong>BPDU Filtering</strong>
<strong>Root Restriction</strong>
<strong>Loopback Detection</strong>
<strong>Link Aggregation</strong>
Compliant with 802.1AX and 802.3ad
<strong>Port Mirroring</strong>
Supports 1 Mirroring group
Supports One-to-One, Many-to-One, Flow-based (ACL) Mirroring
<strong>(Ethernet Ring Protection Switching (ERPS</strong>
|
| استانداردها و قابلیت های پورت |
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3x Flow Control for full-duplex mode, auto-negotiation
|
| Maximum 64-byte Max.
Packet Forwarding Rate |
130.95Mpps
|
| Full/Half-Duplex |
Full/half duplex for 10/100 Mbps and Gigabit speed
|
| Media Interface Exchange |
Auto or configurable MDI/MDIX
|
| ظرفیت سوییچ |
176Gbps
|
| Forwarding Method |
Store-and-forward
|
| جدول MAC Address |
Up to 16,384 entries per device
|
| MAC Address Update |
Up to 512 static MAC entries
Enable/disable auto-learning of MAC addresses
|
| Packet Buffer |
3MB per device
|
| Virtual Stacking |
<strong>D-Link Single IP Management</strong>
Up to 32 units per Virtual Stack
|
| نشانگر LED |
Power/Stacking ID/Fan (per device), Link/Activity/Speed (per 10/100/1000 Mbps port), Link/
(Activity/Speed (per Gigabit SFP port), Link/Activity/Speed (per 10G SFP+ port
|
| MTBF |
416,789hours
|
| منبع تغذیه |
AC Input: 100 to 240 VAC 50/60 Hz
|
| حداکثر توان مصرفی |
44.2W
|
| سایز |
440mm*250mm*44mm
|
| وزن |
2.4kg
|
| سیستم خنک کننده |
2* Smart Fan
|
| نوع Routing/Switching |
Layer 2
|
