| پورت | 24 پورت گیگابیتی شبکه |
|---|
| استانداردها و قابلیت های پورت | IEEE 802.3, 802.3u, 802.3ab compliant
IEEE 802.3z Gigabit fiber
IEEE 802.3x Flow Control
IEEE 802.3az EEE compliant
Half/Full-duplex operation at 10/100Mbps
Full-duplex operation at 1000Mbps
Auto-Negotiation for each port
Auto MDI/MDIX |
|---|
| ظرفیت سوییچ | 48Gbps |
|---|
| Max. Forwarding Rate | 35.71Mpps |
|---|
| جدول MAC Address | 8K |
|---|
| Packet Buffer | 512KBytes |
|---|
| Flash Memory | 8MBytes |
|---|
| Forwarding Method | Store and Forward |
|---|
| منبع تغذیه | 100to 240 VAC, 50 to 60 Hz
Internal Universal Power Supply |
|---|
| Max. Power Consumption | 13.9W |
|---|
| Standby Power Consumption | 10.4W |
|---|
| Heat Dissipation | 47.6BTU/hr |
|---|
| Operating Temperature | 0 تا 40C |
|---|
| Storage Temperature | -10 تا 70C |
|---|
| Operating Humidity | 10%to95%
non-condensing |
|---|
| Storage Humidity | 5%to95%
non-condensing |
|---|
| ابعاد | 280mm*180mm*44mm |
|---|
| وزن | 1.63kg |
|---|
| Certifications | FCC Class A, CE Class A, VCCI Class A |
|---|
| Safety | UL/cUL, CE LVD |
|---|
| MTBF | 2,406,109Hours |
|---|
| VLAN | Port-based VLAN
802.1Q Tagged VLAN
Surveillance VLAN
Voice VLAN
Management VLAN
Max. 4094 VIDs
Supports 128 static VLAN groups |
|---|
| ویژگی های لایه 2 ای | :Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
Supports 64 Groups
:802.3ad Link Aggregation-
12groups, 8 ports per group
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error
:Spanning Tree Protocol-
802.1D STP
802.1w RSTP
SNTP –
L2 Multicast- |
|---|
| QoS | :802.1p Quality of Service-
4queues per port
Queue Handling-
:Bandwidth Control-
Port Based
Ingress: minimum granularity 8 Kbps
Egress: minimum granularity 8 Kbps |
|---|
| امنیت | Traffic Segmentation-
Broadcast/Multicast/Unknown Unicast Storm Control-
:Static MAC Address-
Max. 64 entries
D-Link Safeguard-
DoS Attack Prevention – |
|---|
| مدیریت | Web-Based GUI-
SmartConsole Utility- |
|---|
| D-Link Green | Link Status-
Cable Length-
(Compliant with Energy Efficient Ethernet (IEEE 802.3az-
RoHS Compliant- |
|---|
| سایز جدول MAC Address | 8K |
|---|
| Forwarding Mode | Store and Forward |
|---|
| ویژگی های لایه 2 | :Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
Supports 64 Groups
:802.3ad Link Aggregation-
12groups, 8 ports per group
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error
:Spanning Tree Protocol-
802.1D STP
802.1w RSTP
SNTP –
L2 Multicast- |
|---|
| محل استفاده | Rackmount |
|---|
| تعداد پورت | 18 تا 28 پورت |
|---|
| PoE | None PoE |
|---|
| نوع پورت | Gigabit Ethernet |
|---|
| نوع پورت آپلینک | N/A |
|---|
| نوع Routing/Switching | Layer 2 |
|---|
| برند | D-link |
|---|
