پورت
|
16 پورت گیگابیتی شبکه |
|---|
|
استانداردها و قابلیت های پورت
|
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliance
Supports Half/Full-duplex operation at 10/100Mbps
Supports Full-duplex operation at 1000Mbps
Supports Auto-Negotiation for each port
Auto MDI/MDIX
IEEE 802.3x Flow Control support
IEEE 802.3az compliant |
|---|
|
جدول MAC Address
|
8K |
|---|
|
Packet Buffer
|
512KBytes |
|---|
|
Forwarding Method
|
Store and Forward |
|---|
|
منبع تغذیه
|
100 to 240 VAC, 50 to 60 Hz
Internal Universal Power Supply |
|---|
|
Standby Power Consumption
|
8.0Watts |
|---|
|
Max. Power Consumption
|
9.0Watts |
|---|
|
Operating Temperature
|
0 تا 40C |
|---|
|
Heat Dissipation
|
31.8BTU/hr |
|---|
|
Storage Temperature
|
-10 تا 70C |
|---|
|
Operating Humidity
|
10%to95%
non-condensing |
|---|
|
Storage Humidity
|
5%to95%
non-condensing |
|---|
|
ابعاد
|
280mm x 180mm x 44 mm
11inch Desktop/Rackmount Size
1U Height |
|---|
|
وزن
|
1.5kg |
|---|
|
ظرفیت سوییچ
|
32Gbps |
|---|
|
Max. Forwarding Rate
|
23.81Mpps |
|---|
|
گواهینامه
|
FCC Class A, CE Class A, VCCI Class A |
|---|
|
Safety
|
UL/cUL, CE LVD |
|---|
|
QoS
|
:802.1p Quality of Service-
4queues per port
Queue Handling-
:Bandwidth Control-
Port Based
Ingress: minimum granularity 8 Kbps
Egress: minimum granularity 8 Kbps |
|---|
|
امنیت
|
Traffic Segmentation-
Broadcast/Multicast/Unknown Unicast Storm Control-
:Static MAC Address-
Max. 32 entries |
|---|
|
مدیریت
|
Web-Based GUI-
SmartConsole Utility- |
|---|
|
D-Link Green
|
Link Status-
Cable Length-
(Compliant with Energy Efficient Ethernet (IEEE 802.3az-
RoHS Compliant- |
|---|
|
سایز جدول MAC Address
|
8K |
|---|
|
MTBF
|
2,827,541Hours |
|---|
|
ویژگی های لایه 2
|
:Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
(Supports 32 Groups (DGS-1100-05/-08/-08P
:802.3ad Link Aggregation-
(1group, 2-4 ports per group (DGS-1100-05
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error |
|---|
|
Forwarding Mode
|
Store and Forward |
|---|
|
محل استفاده
|
Desktop , Rackmount |
|---|
|
تعداد پورت
|
16 پورت و کمتر |
|---|
|
PoE
|
None PoE |
|---|
|
نوع پورت
|
Gigabit Ethernet |
|---|
|
نوع پورت آپلینک
|
N/A |
|---|
|
VLAN
|
Port-based VLAN
802.1Q Tagged VLAN
Surveillance VLAN
Voice VLAN
Management VLAN
VLAN Group
(Supports 32 static VLAN groups (DGS-1100-05/-08/-08P
Max. 4094 VIDs |
|---|
|
ویژگی های لایه 2 ای
|
:Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
(Supports 32 Groups (DGS-1100-05/-08/-08P
:802.3ad Link Aggregation-
(1group, 2-4 ports per group (DGS-1100-05
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error |
|---|
|
نوع Routing/Switching
|
Layer 2 |
|---|
|
برند
|
D-link |
|---|
