مشخصات سخت افزاری
|
1/3.25Megapixel CMOS sensor
20meter IR illumination distance
Built-in Infrared-Cut Removable (ICR) Filter module
:Minimum illumination:
0.5Lux Color mode
0.1Lux Black and White mode
0Lux Black and White mode with IR LED on
Minimum object distance 0.3 m
3-10.5mm DC iris vari-focal lens
Aperture F1.4
:Angle of view
H) 25.48° to 85.03°
V) 19.09° to 65.47°
Shutter Speed: 1/2.5 ~ 1/10,000
4x Digital zoom
|
|
بدنه
|
IP66 compliant weatherproof housing
IK-10 compliant vandal-proof housing
Included sunshield
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
Tamper detection
Configurable privacy mask zones
Configurable exposure, brightness, saturation, contrast,
sharpness, white balance, WDR, flip and mirror
|
|
فرمت فشرده سازی ویدیو
|
H.264/MPEG4/MJPEG dual format compression simultaneously
JPEG for still image
H.264/MPEG-4 multicast streaming
|
|
رزولوشن ویدیو
|
16:9 -1280x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176 at up to 30 fps
4:3 – 1024x 768, 800 x 600, 640 x 480, 480 x 360, 320 x 240 at up to 30 fps
|
|
ویژگی های صدا
|
AAC
G.711
|
|
پروتکل های شبکه
|
IPv6
IPv4
TCP/IP
UDP
ICMP
DHCP client
( NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP/ RTCP
IP filtering
QoS
CoS
Multicast
ONVIF compliant
SNMP
|
|
امنیت
|
Administrator and user group protection
Remote client access control
HTTP and RTSP authentication
HTTPS encryption for web access
|
|
D-ViewCam™ SystemRequirements
|
Operating System: Microsoft Windows 7, Vista, XP
Web Browser: Internet Explorer 6 or higher
Protocol: Standard TCP/IP
|
|
مدیریت
|
Motion detection
Tamper Detection
Supports multiple HTTP, SMTP and FTP servers
Multiple event notification
Multiple recording methods for easy backup
Event notification and upload snapshots/video clips via HTTP, SMTP or FTP
|
|
مدیریت از راه دور
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple HTTP, SMTP, and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
ویژگی های نرم افزار مدیریتی
|
Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
|
|
نرم افزارهای تلفن همراه
|
Handsets with 3GPP player, QuickTime 6.5, Real Player 10.5, Windows 2000/ XP/ Vista or 7
|
|
رابط کاربری
|
10/100BASE-TX Ethernet port with PoE
1DI / 1 DO
Reset button
(Video Out (BNC
(microSD card Slot (SD/SDHC
Audio input / output
|
|
منبع تغذیه
|
Input: 12 V DC 1.5 A. 50/60 Hz, IEEE 802.3af PoE Class 0
|
|
نوع
|
DOME
|
|
محل نصب
|
Outdoor
|
|
برند
|
D-link
|
