| رابط کاربری | 24 پورت SFP
4 پورت ترکیبی 10/100/1000BASE-T
پورت کنسول RS-232
3 درگاه آزاد برای پورت های Uplink |
|---|
| Installable Module forStacking | Single-Port DEM-410CX or DEM-410X |
|---|
| No. of Units Per physical Stack | 12 |
|---|
| Switching Fabric | 108Gbps |
|---|
| Packet Forwarding Rate | 80.36Mpps |
|---|
| Packet Buffer | 2MB |
|---|
| IP v4/v6 Routing Table | 12K Entries |
|---|
| MAC Address Table | 16K Entries |
|---|
| IP v4 Host Table | 8K Entries |
|---|
| IP v6 Routing Table | 6K Entries |
|---|
| IP v6 Host Table | 4K Entries |
|---|
| Jumbo Frame Size | 9,216Bytes |
|---|
| منبع تغذیه | 100to 120 V AC, 200 to 240 V AC, 50/60 Hz, Internal Power Supply |
|---|
| Power Consumption | 75.6W |
|---|
| Optional Redundant PowerSupply | DPS-500 |
|---|
| Max Number of StackingPorts Installable | 2 CX4 or XFP Ports |
|---|
| Stacking Speed | (20Gbps (Full-Duplex |
|---|
| Heat Dissipation | 257.96BTU/Hr |
|---|
| Dimensions | 441x 389 x 44 mm |
|---|
| Stackability | Virtual Stacking Support
D-Link Single IP Management v1.6
Up to 32 devices per virtual stack
Up to 20G stacking bandwidth
Physical Stacking
Supports Duplex Chain/Ring topology
Up to 40G stacking bandwidth
Up to 12 units per stack |
|---|
| L2 Features | MAC Address Table: 16K
Flow Control
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frame up to 9,216 Bytes
IGMP snooping
IGMP v1/v2/v3 Snooping
Supports 1 K groups
Port/Host-based
IGMP Snooping
Fast Leave
MLD Snooping
MLD v1 Snooping
Supports 1K groups
Host-based MLD Snooping Fast
Leave
Spanning Tree
802.1D STP
802.1w RSTP
802.1s MSTP
Per port / per device BPDU filtering
Root Restriction
Loopback Detection
802.3ad Link Aggregation
Max. 32 groups per device
8 Gigabit ports or 2 10 Gigabit ports
per group
Port Mirroring
One-to-One
Many-to-One
Flow-based Mirroring
RSPAN
L2 Protocol Tunneling
ERPS (Ethernet Ring Protection Switching) |
|---|
| VLAN | VLAN Group
Max. 4K Static VLAN Groups
Max. 255 Dynamic VLAN Groups
802.1Q Tagged VLAN
802.1v Protocol VLAN
GVRP
(Double VLAN (Q-in-Q
Port-based Q-in-Q
Selective Q-in-Q
MAC-based VLAN
VLAN Trunking
Super VLAN |
|---|
| L3 Features | 256 IP interfaces
Loopback interface
VRRP
IPv6 Tunneling
Static
ISATAP
GRE
6to4
IPv6 Ready Phase 1/2
Proxy ARP
Gratuitous ARP |
|---|
| L3 Routing | 12K hardware routing entries shared by IPv4/v6
Max. 12K IPv4 routes
Max. 6K IPv6 routes
8K hardware L3 forwarding entries shared by IPv4/v6
Max. 8K IPv4 entries
Max. 4K IPv6 entries
256static routing entries for IPv4, 128 entries for IPv6
Supports ECMP/WCMP
Policy-based Routing
RIP v1/v2
(RIPng (IPv6) |
|---|
| Size | 19nch Rack-Mount Width, 1U Height |
|---|
| Management | Web-based GUI
(Command Line Interface (CLI
Telnet Server
Telnet Client
TFTP Client
ZModem
SNMP v1/v2c/v3
SNMP Trap
System Log
RMON v1
RMON v2
sFlow
LLDP
BootP/DHCP Client
DHCP Auto-Configuration
DHCP Relay
DHCP Relay Option 60; 61 *
DHCP Relay Option 82
DHCP Server
Flash File System
Multiple Images
Multiple Configurations
CPU Monitoring
Debug Command
SNTP
ICMPv6 |
|---|
| Security | SSH v1/v2
SSL v1/v2/v3
Port Security up to 16 MAC addresses
per port
Broadcast/Multicast/Unicast Storm Control
Traffic Segmentation
IP-MAC-Port Binding
ARP Packet Inspection
IP Packet Inspection
DHCP Snooping
DHCPv6 and NDP Snooping
Supports up to 500 Address Binding
Entries per device
D-Link Safeguard Engine
DHCP Server Screening
CPU Interface Filtering
ARP Spoofing Prevention
BPDU Attack Protection |
|---|
| محل استفاده | Rackmount |
|---|
| تعداد پورت | 18 تا 28 پورت |
|---|
| PoE | None PoE |
|---|
| نوع پورت | Copper/SFP Gigabit combo, Gigabit Ethernet, SFP Gigabit |
|---|
| نوع پورت آپلینک | Copper 10 Gigabit, Copper/SFP 10 Gigabit Combo, SFP 10 Gigabit |
|---|
| Weight | 5.5kg |
|---|
| MTBF | 289,946hours |
|---|
| نوع Routing/Switching | Layer 3 |
|---|
| برند | D-link |
|---|
نقد و بررسیها
هنوز بررسیای ثبت نشده است.
