رابط کاربری
|
20 پورت گیگابیتی شبکه
4 پورت ترکیبی 10/100/1000BASE-T/SFP
2 پورت +10G SFP |
|---|
|
پورت console
|
RJ-45 Console Port |
|---|
|
استانداردها و امکانات پورت
|
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x Flow Control for full-duplex mode, auto-negotiation |
|---|
|
Full/Half-Duplex
|
Half/full-duplex for 10/100 Mbps and full-duplex for 1000 Mbps speeds |
|---|
|
Flash Memory
|
32MB |
|---|
|
ظرفیت سوییچ
|
88Gbps |
|---|
|
Forwarding Method
|
Store-and-forward |
|---|
|
سایز جدول MAC Address
|
Up to 16K entries per device |
|---|
|
MAC Address Update
|
Up to 512 static MAC entries |
|---|
|
Maximum 64-byte Max.Packet Forwarding Rate
|
65.48Mpps |
|---|
|
Packet Buffer
|
2MB per device |
|---|
|
نشانگر LED
|
(Power (per device
(Redundant Power Supply (RPS) (per device
(Console (per device
(Link/Active/Speed (per port |
|---|
|
MTBF
|
344,512hours |
|---|
|
منبع تغذیه
|
AC Input: 100 to 240 VAC 50/60 Hz |
|---|
|
حداکثر مصرف انرژی
|
35.5W |
|---|
|
ابعاد
|
440*210*44 میلیمتر |
|---|
|
Stacking
|
Virtual Stacking
(D-Link Single IP Management (SIM
Up to 32 units per virtual stack Physical Stacking
Up to 40G Stacking Bandwidth
Up to 6 units per Stack |
|---|
|
ویژگی های L2
|
<strong>Flow Control</strong>
802.3x Flow Control
HOL Blocking Prevention
<strong> Jumbo Frames up to 9216 Bytes</strong>
<strong>Spanning Tree Protocols</strong>
802.1D STP
802.1w RSTP
802.1s MSTP
<strong>BPDU Filtering</strong>
<strong>Root Restriction</strong>
<strong>Loopback Detection</strong>
<strong>Link Aggregation</strong>
Compliant with 802.1AX and 802.3ad
<strong>Port Mirroring</strong>
Supports 1 Mirroring group
Supports One-to-One, Many-to-One, Flow-based (ACL) Mirroring
<strong>(Ethernet Ring Protection Switching (ERPS</strong> |
|---|
|
L2 Multicasting
|
<strong>IGMP Snooping</strong>
IGMP v1/v2 Snooping, v3 awareness
Supports 1024 groups
Port/Host-based IGMP Snooping Fast Leave
Report Suppression
IGMP Authentication
(Limited IP Multicast (IGMP Filtering
<strong>MLD Snooping</strong>
MLD v1, MLD v2 awareness
Supports 1024 groups
Port/Host-based MLD snooping Fast Leave |
|---|
|
VLAN
|
<strong>VLAN Group</strong>
Max. 4094 VLAN
<strong>Port-based VLAN</strong>
<strong>MAC-based VLAN</strong>
<strong>GVRP</strong>
Max. 255 dynamic VLANs
<strong>802.1v Protocol VLAN</strong>
<strong>802.1Q Tagged VLAN</strong>
<strong>(Double VLAN (Q-in-Q</strong>
Port-based Q-in-Q
<strong>ISM VLAN</strong>
<strong>VLAN Translation</strong>
<strong>VLAN Trunking</strong> |
|---|
|
ویژگی های لایه 3 ای
|
Max. 1024 ARP entries
(IPv6 Neighbor Discovery (ND
16IP interfaces
Default Route
Static Route |
|---|
|
(Quality of Service (QoS
|
<strong>CoS based on</strong>
Switch Port
802.1p Priority
VLAN ID
MAC Address
Ether Type
IPv4/IPv6 address
DSCP
ToS
Protocol Type
TCP/UDP Port
IPv6 Traffic Class
IPv6 Flow Label
User Defined Packet Content
<strong>Bandwidth Control</strong>
(Port-based (Ingress, Min. Granularity 64 Kbps
(Flow-based (Ingress, Min. Granularity 64 Kbps
(Egress queue bandwidth control (Min. Granularity 64 Kbps
<strong>Queue Handling</strong>
(Strict Priority Queue (SPQ
(Weighted Round Robin (WRR
SPQ + WRR
<strong>8queues per port</strong> |
|---|
|
امنیت
|
SSH v1/v2
SSL v1/v2/v3
Port Security
Broadcast/Multicast/Unicast Storm Control
(IP-MAC-Port Binding (IMPB)
Traffic Segmentation
D-Link Safeguard Engine
L3 Control Packet Filtering
NetBIOS/NetBEUI Filtering
DHCP Server Screening
DHCP Client Filtering
ARP Spoofing Prevention
BPDU Attack Protection
DoS Attack Prevention |
|---|
|
OAM
|
Cable Diagnostics
802.3ah Ethernet Link OAM
Dying Gasp
(802.1ag Connectivity Fault Management (CFM) |
|---|
|
مدیریت
|
(Web-based GUI (Supports IPv4/v6
(Command Line Interface (CLI
(Telnet Server/Client (Supports IPv4
(TFTP/FTP Client (Supports IPv4
ZModem
Command Logging
( SNMP v1/v2c/v3 (Supports IPv4
SNMP Traps
System Log
( SMTP (IPv4
802.1AB LLDP
LLDP-MED
(BootP/DHCP Client (Supports IPv4
DHCP Auto-Configuration1
(DHCP Relay (Supports IPv4
DHCP Relay Option 60, 61 and 82
DHCP Client Option 12
PPPoE Circuit-ID Tag Insertion
Multiple Image
Flash File System
CPU Monitoring
Memory Monitoring
(SNTP (Supports IPv4
Debug Command
Password Recovery
Password Encryption
Ping
Traceroute
(Microsoft® NLB (Network Load Balancing) Support (Supports IPv4
(Zero Touch Provisioning (ZTP
sFlow1
D-Link Network Assistant1 |
|---|
|
Green
|
(IEEE 802.3az Energy Efficient Ethernet (EEE
Power-saving function
Link Status
Cable Length
LED Shut-Off
Port Shut-Off
Port Standby
System Hibernation |
|---|
|
محل استفاده
|
Rackmount |
|---|
|
تعداد پورت
|
18 تا 28 پورت |
|---|
|
PoE
|
None PoE |
|---|
|
نوع پورت
|
Gigabit Ethernet |
|---|
|
نوع پورت آپلینک
|
Copper/SFP Gigabit combo , Gigabit Ethernet , SFP Gigabit |
|---|
|
نوع Routing/Switching
|
Layer 3 |
|---|
|
برند
|
D-link |
|---|
