| رابط های کاربری | 48 پورت گیگابیتی PoE
4 پورت SFP |
|---|
| پورت های PoE | Ports 1~8 compliant with 802.3at
Ports 9~48 compliant with 802.3af |
|---|
| Media Interface Exchange | Auto MDI/MDIX adjustment for all twisted-pair ports |
|---|
| ظرفیت سوییچ | 104Gbps |
|---|
| Transmission Method | Store-and-forward |
|---|
| جدول MAC Address | 16k |
|---|
| Maximum 64 bytes packetforwarding rate | 77.4Mpps |
|---|
| MAC Address Update | Up to 256 static MAC entries |
|---|
| DDRIII for CPU | 128Mbytes |
|---|
| Packet Buffer | 3.0MB |
|---|
| Flash Memory | 16Mbytes |
|---|
| منبع تغذیه | 100to 240 VAC 50/60 Hz internal universal power supply |
|---|
| حداکثر توان مصرفی | (483.1watts(PoE on
(48.9watts(PoE off |
|---|
| حداکثر توان PoE | 370W |
|---|
| مصرف برق در حالت Standby | 29.5W/100V
27.5W/240V |
|---|
| ویژگی ها و استانداردهای پورت | (IEEE 802.3 10BASE-T Ethernet (twisted-pair copper
(IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper
(IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper
IEEE 802.3az compliance
Auto-negotiation
IEEE 802.3x Flow Control
IEEE802.3, IEEE802.3u, IEEE802.3ab
IEEE802.3az
IEEE802.3z |
|---|
| Full/Half-Duplex | Full/half duplex for 10/100 Mbps speeds
Full duplex for Gigabit speed |
|---|
| اتلاف حرارت | 1,648.23Btu/hr |
|---|
| ابعاد | 440mm*430mm*44mm |
|---|
| Green Technology | Link Status
Time-based PoE: PoE ports can be turned on/off by port or system through schedule
LED Shutoff
System Hibernation
Port Shutoff |
|---|
| MTBF | 318,616hours |
|---|
| ویژگی های لایه 2 ای | IGMP Snooping
IGMP v1/v2 Snooping
Supports 256 IGMP groups
Supports at least 64 static multicast addresses
IGMP per VLAN
Supports IGMP Snooping Querier
Loopback Detection
:802.3ad Link Aggregation
Maximum of 26 groups/8 ports per group
LLDP
LLDP-MED
Jumbo Frame
Up to 9,216 bytes
Spanning Tree Protocol
802.1D STP
802.1w RSTP
Flow Control
802.3x Flow Control
HOL Blocking Prevention
Port Mirroring
One-to-One
Many-to-One
Supports Mirroring for Tx/Rx/Both
Multicast Filtering
Forwards all unregistered groups
Filters all unregistered groups
Configurable MDI/MDIX
(MLD snooping v1/v2 (256 groups |
|---|
| VLAN | 802.1Q
VLAN Group
Max. 256 static VLAN groups
Configurable VID from 1 – 4094
Asymmetric VLAN
Auto Voice VLAN
Max. 10 user-defined OUI
Max. 8 default OUI
Auto Surveillance VLAN |
|---|
| QoS | Max. 50 access list
Max. 768 rules shared by IPv4, MAC and IPv6
Each rule can only be associated with a single port
ACL based on
802.1p priority
VLAN
MAC address
Ether type
IP address
DSCP
Protocol type
TCP/UDP port number
IPv6 Traffic Class |
|---|
| امنیت | Broadcast/Multicast/Unicast Storm Control
D-Link Safeguard Engine
DHCP Server Screening
(IP-MAC-Port Binding (Smart Binding
Supports 512 address binding entries
ARP Inspection
ARP + IP Inspection
Supports DHCP Snooping
802.1X Port-based Access Control
ARP Spoofing Prevention
Max. 64 entries
Traffic Segmentation
SSH v2
SSL
Supports v1/v2/v3
Port Security
Supports up to 64 MAC addresses per port
Duplicate address detection |
|---|
| وزن | 5.78kg |
|---|
| مدیریت | Web-based GUI
D-Link Network Assistant Utility
Compact CLI
Telnet Server
TFTP Client
Configurable MDI/MDIX
SNMP
Supports v1/v2c/v3
SNMP Trap
Backup/Upgrade firmware
Smart Wizard
Upload/Download Configuration file
System Log
Max. 500 log entries
BootP/DHCP Client
SNTP
ICMP v6
IPv4/v6 Dual Stack
DHCP Auto Configuration
Time Setting
SNTP
RMONv1
Trusted Host |
|---|
| AAA | 802.1X Authentication
IPv6 RADIUS Server
Support MD5 authentication |
|---|
| محل استفاده | Rackmount |
|---|
| تعداد پورت | 48 پورت و بالاتر |
|---|
| PoE | 802.11af, 802.11at |
|---|
| نوع پورت | Gigabit Fiber |
|---|
| نشانگر LED | (Link/Activity/Speed (Per 10/100/1000 Mbps port |
|---|
| گواهینامه | CE Class A
VCCI Class A
FCC Class A
BSMI
CCC
C-Tick
cUL
(CE (LVD |
|---|
| نوع پورت آپلینک | Copper/Gigabit Fiber combo, Gigabit Ethernet, Gigabit Fiber |
|---|
| برند | D-link |
|---|
