رابط های کاربری
|
24 پورت گیگابیتی PoE
4 پورت SFP
|
|
پورت های PoE
|
Ports 1 to 24 compliant with 802.3at
|
|
Media Interface Exchange
|
Auto MDI/MDIX adjustment for all twisted-pair ports
|
|
ظرفیت سوییچ
|
56Gbps
|
|
Transmission Method
|
Store-and-forward
|
|
جدول MAC Address
|
16k
|
|
Maximum 64 bytes packetforwarding rate
|
41.7Mpps
|
|
MAC Address Update
|
Up to 256 static MAC entries
|
|
CPU Memory
|
256MB DDR3
|
|
Packet Buffer
|
1.5MB
|
|
Flash Memory
|
32Mbytes
|
|
منبع تغذیه
|
100to 240 VAC 50/60 Hz internal universal power supply
|
|
حداکثر توان مصرفی
|
(454.4watts(PoE on
(33.1watts(PoE off
|
|
حداکثر توان PoE
|
370W
|
|
مصرف برق در حالت Standby
|
29.5W/100V
27.5W/240V
|
|
ویژگی ها و استانداردهای پورت
|
(IEEE 802.3 10BASE-T Ethernet (twisted-pair copper
(IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper
(IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper
IEEE 802.3az compliance
Auto-negotiation
IEEE 802.3x Flow Control
IEEE802.3, IEEE802.3u, IEEE802.3ab
IEEE802.3az
IEEE802.3z
|
|
Full/Half-Duplex
|
Full/half duplex for 10/100 Mbps speeds
Full duplex for Gigabit speed
|
|
اتلاف حرارت
|
1,648.23Btu/hr
|
|
ابعاد
|
440mm*250mm*44mm
|
|
Green Technology
|
Link Status
Time-based PoE: PoE ports can be turned on/off by port or system through schedule
LED Shutoff
System Hibernation
Port Shutoff
|
|
MTBF
|
271,281hours
|
|
ویژگی های لایه 2 ای
|
<strong>IGMP Snooping</strong>
IGMP v1/v2 Snooping
Supports 256 IGMP groups
Supports at least 64 static multicast addresses
IGMP per VLAN
Supports IGMP Snooping Querier
<strong>Loopback Detection</strong>
<strong>:802.3ad Link Aggregation</strong>
<strong> Maximum of 26 groups/8 ports per group
LLDP</strong>
<strong> LLDP-MED</strong>
<strong>Jumbo Frame</strong>
Up to 9,216 bytes
<strong>Spanning Tree Protocol</strong>
802.1D STP
802.1w RSTP
<strong>Flow Control</strong>
802.3x Flow Control
HOL Blocking Prevention
<strong>Port Mirroring</strong>
One-to-One
Many-to-One
Supports Mirroring for Tx/Rx/Both
<strong>Multicast Filtering</strong>
Forwards all unregistered groups
Filters all unregistered groups
<strong>Configurable MDI/MDIX</strong>
(MLD snooping v1/v2 (256 groups
|
|
VLAN
|
<strong>802.1Q</strong>
<strong>VLAN Group</strong>
Max. 256 static VLAN groups
<strong>Configurable VID from 1 – 4094</strong>
<strong>Asymmetric VLAN</strong>
<strong>Auto Voice VLAN</strong>
Max. 10 user-defined OUI
Max. 8 default OUI
<strong>Auto Surveillance VLAN</strong>
|
|
QoS
|
<strong>Max. 50 access list</strong>
<strong>Max. 768 rules shared by IPv4, MAC and IPv6</strong>
<strong>Each rule can only be associated with a single port</strong>
<strong>ACL based on</strong>
802.1p priority
VLAN
MAC address
<strong>Ether type</strong>
<strong>IP address</strong>
<strong>DSCP</strong>
<strong>Protocol type</strong>
<strong>TCP/UDP port number</strong>
<strong>IPv6 Traffic Class</strong>
|
|
امنیت
|
<strong>Broadcast/Multicast/Unicast Storm Control</strong>
<strong>D-Link Safeguard Engine</strong>
<strong>DHCP Server Screening</strong>
<strong>(IP-MAC-Port Binding (Smart Binding</strong>
Supports 512 address binding entries
ARP Inspection
ARP + IP Inspection
Supports DHCP Snooping
<strong>802.1X Port-based Access Control</strong>
<strong>ARP Spoofing Prevention</strong>
Max. 64 entries
<strong>Traffic Segmentation</strong>
<strong>SSH v2</strong>
<strong>SSL</strong>
Supports v1/v2/v3
<strong>Port Security</strong>
Supports up to 64 MAC addresses per port
<strong>Duplicate address detection</strong>
|
|
وزن
|
3.86kg
|
|
مدیریت
|
<strong>Web-based GUI</strong>
<strong>D-Link Network Assistant Utility</strong>
<strong>Compact CLI</strong>
<strong>Telnet Server</strong>
<strong>TFTP Client</strong>
<strong>Configurable MDI/MDIX</strong>
<strong>SNMP</strong>
Supports v1/v2c/v3
<strong>SNMP Trap</strong>
Backup/Upgrade firmware
<strong>Smart Wizard</strong>
<strong>Upload/Download Configuration file</strong>
<strong>System Log</strong>
Max. 500 log entries
<strong>BootP/DHCP Client</strong>
<strong>SNTP</strong>
<strong>ICMP v6</strong>
<strong>IPv4/v6 Dual Stack</strong>
<strong>DHCP Auto Configuration</strong>
<strong>Time Setting</strong>
SNTP
<strong>RMONv1</strong>
<strong>Trusted Host</strong>
|
|
AAA
|
802.1X Authentication
IPv6 RADIUS Server
Support MD5 authentication
|
|
محل استفاده
|
Rackmount
|
|
تعداد پورت
|
18 تا 28 پورت
|
|
PoE
|
802.11af
,
802.11at
|
|
نوع پورت
|
Gigabit Ethernet
|
|
نشانگر LED
|
(Link/Activity/Speed (Per 10/100/1000 Mbps port
|
|
گواهینامه
|
CE Class A
VCCI Class A
FCC Class A
BSMI
CCC
C-Tick
cUL
(CE (LVD
|
|
نوع پورت آپلینک
|
Copper/Gigabit Fiber combo
,
Gigabit Ethernet
,
Gigabit Fiber
|
|
برند
|
D-link
|
