سایز
|
190mm*120mm*38mm
|
|
رابط های کاربری
|
5 پورت گیگابیتی شبکه
1 پورت 100/1000 SFP
|
|
ظرفیت سوییچ
|
12Gbps
|
|
64byte Maximum Forwarding Rate
|
8.9Mpps
|
|
جدول MAC Address
|
4K
|
|
SDRAM for CPU
|
128MB
|
|
Packet Buffer
|
128KB
|
|
Flash Memory
|
16B
|
|
Jumbo Frame
|
9216Bytes
|
|
نشانگر LED
|
(Power (per device
(Link/Activity/Speed (per port
|
|
Power Consumption
|
Standby Mode : 3.62 watts
Maximum : 7.08 watts
|
|
منبع تغذیه
|
External Power Adapter: 100 to 240 V AC, 50 to 60 Hz
Output: 12 V/1 A
|
|
MTBF
|
459,420hours
|
|
Heat Dissipation
|
24.16BTU/hr
|
|
وزن
|
0.42kg
|
|
EMI
|
CE Class A
|
|
Safety
|
CE LVD, UL/cUL
|
|
ویژگی های لایه 2 ای
|
MAC Address Table: 4K-
:802.3x Flow Control-
HOL Blocking Prevention
Loopback Detection-
:Port Mirroring-
Supports one mirroring group-
One-to-One-
Many-to-One-
|
|
Multicasting L2
|
:IGMP Snooping-
IGMP v1/v2 Snooping, v3 Awareness
Supports 32 Groups
Port-based IGMP snooping Fast Leave
IGMP Authentication-
Limited IP Multicast-
:MLD Snooping-
MLD Snooping v1, v2
Supports 32 MLD Snooping groups
Port-based MLD Snooping Fast Leave
|
|
VLAN
|
802.1Q Tagged VLAN-
:VLAN Group-
Supports 32 static VLAN groups
Management VLAN-
Port-based VLAN-
ISM VLAN-
:(Double VLAN (Q-in-Q-
Port-based Q-in-Q
|
|
QoS
|
4queues per port-
:Queue Handling-
Strict Priority
(Weighted Round Robin (WRR
:Bandwidth Control-
(Port-based (Ingress/Egress, min. granularity 64 Kb/s
:CoS Based on-
802.1p
DSCP
IPv6 Traffic Class
|
|
امنیت
|
: Port Security-
Up to 64 MAC addresses per port
Traffic Segmentation-
Broadcast/Multicast/Unknown Unicast Storm Control-
D-Link Safeguard Engine-
|
|
AAA
|
:802.1X-
Port-based Access Control
Host-based Access Control
Supports Guest VLAN-
Support Local/RADIUS Servers-
Support RADIUS Accounting-
4Levels of User Accounts-
|
|
OAM
|
Cable Diagnostics
802.3ah
|
|
مدیریت
|
Web-based GUI
(Command Line Interface (CLI
Telnet Server
TFTP Client
SNMP v1/v2c/v3
SNMP Traps
System Log
RMON v1
LLDP
BootP/DHCP Client
DHCP Auto-Configuration
DHCP Relay for IPv4/IPv6
DHCP Relay Option 82
DHCP Relay Option 37
PPPoE Circult-ID Tag Insertion
SNTP
CPU Monitoring
Password Encryption
|
|
MIB
|
RFC1213 MIB II
RFC1493 Bridge MIB
RFC1907 SNMPv2 MIB
RFC1398, 1643, 1650, 2358, 2665 Ether-like MIB
RFC 2233, 2863 IF MIB
RFC 2618 RADIUS Authentication Client MIB
RFC2620 RADIUS Accounting Client MIB
Private MIB
|
|
IETF Standard
|
RFC768 UDP
RFC791 IP
RFC792,2463, 4443 ICMPv4
RFC793 TCP
RFC826 ARP
RFC 2474, 3260 Definition of the DS Field in the IPv4 and IPv6 Header
(RFC 1321, 2284, 2865, 3580, 3748 Extensible Authentication Protocol (EAP
RFC2571, RFC2572, RFC2573, RFC2574 SNMP
RFC1981, RFC2460, RFC2461,4861, RFC2462,4862, RFC2464, RFC3513,4291, RFC2893,4213
|
|
سایز جدول MAC ADDRESS
|
4K
|
|
ویژگی های لایه 2
|
MAC Address Table: 4K-
:802.3x Flow Control-
HOL Blocking Prevention
Loopback Detection-
:Port Mirroring-
Supports one mirroring group-
One-to-One-
Many-to-One-
|
|
(Quality of Service (QoS
|
4queues per port-
:Queue Handling-
Strict Priority
(Weighted Round Robin (WRR
:Bandwidth Control-
(Port-based (Ingress/Egress, min. granularity 64 Kb/s
:CoS Based on-
802.1p
DSCP
IPv6 Traffic Class
|
|
محل استفاده
|
Desktop
|
|
تعداد پورت
|
16 پورت و کمتر
|
|
PoE
|
None PoE
|
|
نوع پورت
|
Gigabit Ethernet
|
|
نوع پورت آپلینک
|
N/A
|
|
نوع Routing/Switching
|
Layer 2
|
|
برند
|
D-link
|
