| سایز | 150mm*97mm*28mm |
|---|
| رابط های کاربری | 5 پورت گیگابیتی شبکه
پورت 1-2 PoE
پورت 5 ام PoE PD |
|---|
| ویژگی های پورت | IEEE 802.3 for Ethernet
IEEE 802.3u for Fast Ethernet
IEEE 802.3ab for Gigabit Ethernet |
|---|
| ظرفیت سوییچ | 10Gbps |
|---|
| 64byte Maximum Forwarding Rate | 7.44Mpps |
|---|
| جدول MAC Address | 2K |
|---|
| Packet Buffer | 1Mbit |
|---|
| Flash Memory | 2MB |
|---|
| استاندارد PoE | 802.3af |
|---|
| پورت های PoE | پورت 1 و 2
15.4w max per PoE port |
|---|
| ظرفیت کلی PoE | 18W with 802.3at
8W with 802.3af input power |
|---|
| نشانگر LED | (Power (per device
(Link/Activity/Speed (per port |
|---|
| Power Consumption | Standby Mode : 1.46 watts
(Maximum : 23.92 W (PoE on
(2.23w (PoE off |
|---|
| منبع تغذیه | 802.3af/at PoE input only
(No power supply) |
|---|
| MTBF | 2,346,941hours |
|---|
| وزن | 0.38kg |
|---|
| EMI | FCC Class B, CE Class B, VCCI Class B, BSMI, CCC |
|---|
| Safety | cUL, CE LVD, CB, BSMI, CCC |
|---|
| ویژگی های لایه 2 ای | :Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMP v1/v2 Snooping
Supports 32 Groups
: Static Trunk-
2groups, 2-4 ports per group
Loopback Detection-
Cable Diagnostics-
:Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error |
|---|
| VLAN | Port-based VLAN-
802.1Q tagged VLAN-
Surveillance VLAN-
Voice VLAN-
Management VLAN-
: VLAN Group-
Supports 32 static VLAN groups
Max. 4094 VIDs |
|---|
| QoS | 4queues per port-
:Queue Handling-
Strict Priority
(Weighted Round Robin (WRR
:Bandwidth Control-
(Port-based (Ingress/Egress, min. granularity 64 Kb/s
:CoS Based on-
802.1p
DSCP
IPv6 Traffic Class |
|---|
| امنیت | : Port Security-
Up to 32 MAC addresses per port
Traffic Segmentation-
Broadcast/Multicast/Unknown Unicast Storm Control- |
|---|
| مدیریت | (Web-based GUI (Supports IPv4
(Client-based Utility (SmartConsole Utility |
|---|
| IETF Standard | RFC768 UDP
RFC791 IP
RFC792,2463, 4443 ICMPv4
RFC793 TCP
RFC826 ARP
RFC 2474, 3260 Definition of the DS Field in the IPv4 and IPv6 Header
(RFC 1321, 2284, 2865, 3580, 3748 Extensible Authentication Protocol (EAP
RFC2571, RFC2572, RFC2573, RFC2574 SNMP
RFC1981, RFC2460, RFC2461,4861, RFC2462,4862, RFC2464, RFC3513,4291, RFC2893,4213 |
|---|
| محل استفاده | Desktop |
|---|
| تعداد پورت | 16 پورت و کمتر |
|---|
| PoE | 802.11af, 802.11at |
|---|
| نوع پورت | Gigabit Ethernet |
|---|
| نوع پورت آپلینک | Gigabit Ethernet |
|---|
| برند | D-link |
|---|
