| مشخصات فنی | <strong>Identification: ID plate, PVC, Transparent color with paper</strong>
<strong> Panel: SPCC, 1.5mm thickness with Black (RAL 9005) color painted</strong>
<strong>:RJ45 Jack</strong>
Housing: ABS, UL 94V-0
Contact Brackets: PC, UL 94V-2, Transparent color
<strong>: RJ45 Jack Contact</strong>
Material: Phosphor Bronze with Nickel Plated
Finish: 50 micro-inches Gold plated on plug contact area
<strong>: IDC</strong>
Housing: PC+ Glass Fiber, UL 94V-2
Terminal: phosphor Bronze with Tin plated
<strong>Jack Bracket Set: ABS, UL 94V-0</strong>
<strong>Support Bar: SPCC, 1.5 mm thickness</strong>
with Black (RAL 9005) color painted
<strong>PCB: FR4, UL 94V-0</strong> |
|---|
| کارایی | T568A & T568B wiring scheme on PCB
(Insertion force: 30N max. (IEC 60603-7-5)
Retention strength: 7.7 kg between jack and plug
: Operating temperature: -10°C to 60°C
( ISO/IEC 11801, ANSI/TIA/EIA 568B.2)
:(Life ( mating cycles
a. Jack: 750 cycle’s min (ISO/IEC 11801, IEC 60603-7-5
b. IDC: suitable for 22-26 AWG stranded and solid wire, compatible with both 110& Krone punch down tools
The Cat6 transmission performance is in compliance
with the ANSI/TIA/EIA 568B.2 -1 standard
Six port modules applied |
|---|
