| استاندارد | IEEE 802.3/u/z
Auto MDI/MDI-X
SATA I, II |
|---|
| HDD | HDD control & manage via PC
Reformat Disk
RAID 0 , 1
JBOD |
|---|
| امنیت | Cover lock
Security lock |
|---|
| Flash ROM | 32MB |
|---|
| RAM | 128MB DDR II |
|---|
| رابط کاربری شبکه | ( Gigabit Ethernet LAN port (10/100/1000 Mbps |
|---|
| پورت I/O | RJ-45 port
DC-in jack
USB port for UPS status update |
|---|
| منبع تغذیه | DC 12 V/4 A |
|---|
| ابعاد | 115x 146.4 x 178.5 mm |
|---|
| حداکثر مصرف انرژی | 25.20W |
|---|
| دوربین های قابل پشتیبانی | Supports all D-Link network cameras. Includes support
for auto-discovery and megapixel resolution
Supports known-brand network cameras including
D-Link, Axis, Panasonic, Sony, Mobotix, Arecont Vision, IQinVision, Cisco, and Acti |
|---|
| عملکرد ضبط | :(Max. capacity (NVR mode only
H.264 1080P (bitrate): 90 Mbps
H.264 720P (bitrate): 90 Mbps
MJPEG 1080P (frame rate): 90 fps
MJPEG 720P (frame rate): 192 fps
:(Max. capacity (NVR+File Server mode
H.264 1080P (bitrate): 68 Mbps
H.264 720P (bitrate): 68 Mbps
MJPEG 1080P (frame rate): 70 fps
MJPEG 720P (frame rate): 150 fps |
|---|
| ضبط ویدیو و صدا | Synchronized audio & video recording |
|---|
| فرمت های فشرده سازی | (H.264, MPEG-4, M-JPEG (for supported cameras |
|---|
| تنظیمات ویدیو | Resolution, quality, frame rate, enable audio, go to
camera interface |
|---|
| نوع ضبط | Record by schedule, manual, and event-based recording
Motion-triggered recording |
|---|
| Remote Live View | ( Supported via IE Explorer (Max. 9 simultaneous channels Supports mydlink portal (Max. 1 simultaneous channel |
|---|
| Overwrite Recording | Auto recycling when disk storage is full |
|---|
| فایل خروجی | Export videos to AVI or ASF file
Export images to BMP or JPG file |
|---|
| مدیریت کاربر | Additional accounts can be created to allow user access
to the system and specify authorization for camera
channels, PTZ, etc |
|---|
| DDNS | D-Link DDNS server support |
|---|
| Remote Backup | Remote software can back up raw data to redundant storage
Auto backup of previous day’s video to FTP server |
|---|
| System Status | Camera status
Still picture EMAP support
System status |
|---|
| Network Service Protocols | IPV4, ARP, TCP, UDP, ICMP
DHCP Client
( NTP Client (D-Link
DNS Client
( DDNS Client (D-Link
SMTP Client
HTTP Server
PPPoE
UPnP
IP filtering |
|---|
| برند | D-link |
|---|
