سایز
|
19inch Sandard Rack-Mount Width, 1U Height
|
|
رابط کاربری
|
20-10/100/1000Base-T
4 Combo 10/100/1000Base-T/SFP
|
|
پورت کنسول
|
RJ45
|
|
سایز جدول MAC Address
|
(467W (full POE load
|
|
ظرفیت سوییچ
|
48Gbps
|
|
Maximum ForwardingRate
|
35.71Million Packets per Second
|
|
Forwarding Method
|
Store and Forward
|
|
Packet Buffer Memory
|
2MB
|
|
802.3af Power overEthernet
|
15.4W Per Port
370W Total Power Budget
740W Total Power Budget With RPS
|
|
تعداد VLAN
|
3,965
|
|
Static Routes
|
512
|
|
Jumbo Frames
|
13K
|
|
MTBF
|
282,541hours
|
|
ابعاد
|
440x 210 x 44 mm
|
|
مدیریت
|
Manages up to 48 Unified Access Points per switch, up to 192 APs per cluster
Switch Cluster for Single IP Management
SSH
SSL
SNMP v1, 2c, 3
sFlow
Dual Image Support
Web GUI
Command Line Interface
|
|
مدیریت اکسس پوینت
|
AP Auto-Discovery
Remote AP Reboot
AP Monitoring: List Managed AP, Rogue AP,
Authentication Failed AP
Client Monitoring: List clients associated with each Managed AP
Ad-hoc Client Monitoring
AP Authentication Supporting Local Database and
External RADIUS Server
Centralized RF/Security Policy Management
Automatic AP RF Channel Adjustment
Automatic AP Transmit Output Power Adjustment
Centralized Firmware Upgrade
|
|
Roaming
|
Fast Roaming
Intra-Switch/Inter-Switch Roaming
Intra-Subnet/Inter-Subnet Roaming
|
|
Access Control & Bandwidth Management
|
(Up to 32 SSID per AP (16 SSID per frequency band
AP Load Balancing based on the number of users or AP utilization
Flexible Mapping Schemes
|
|
ویژگی های L2
|
IGMP Snooping
MLD Snooping
802.1D/w/s Spanning Tree
802.3ad Link Aggregation
802.1ab LLDP
(Port Mirroring (One-to-One and Many-to-One
Jumbo Frame Size: Up to 13 KB
|
|
ویژگی های L3
|
IPv4/v6 Static Route
Routing Table Size: 512 Static Routes
VRRP
ARP Proxy
|
|
امنیت LAN
|
RADIUS Authentication Management Access
TACACS+ Authentication for Management Access
SSH & SSL Support
MAC Filtering
802.1X Port-based Access Control & Guest VLAN
Denial of Service Protection
Dynamic ARP Inspection
Protected Port
Broadcast Storm Control
Access Control List
|
|
LAN Flow Control
|
802.3x Standard in Full Duplex Mode
Back Pressure in Half Duplex Mode
Head-of-Line Blocking Prevention
|
|
QoS
|
Voice VLAN
(Wireless Multimedia (WMM
802.1p Priority Queues
CoS-based QoS
Per-Flow Bandwidth Control
Per-Port Traffic Shaping
Minimum Bandwidth Guarantee
|
|
VLAN
|
802.1Q VLAN Tagging
802.1V
Subnet-based VLAN
MAC-based VLAN
GVRP
Double VLAN
Voice VLAN
|
|
WLAN امنیت
|
WPA Personal/Enterprise
WPA2 Personal/Enterprise
64/128/152-bit WEP Data Encryption
MAC Authentication
Station Isolation
Wireless Station and AP Monitoring based on RF
Channel, MAC Address, SSID, Time
Rogue AP and Client Detection & Mitigation
Captive Portal
Security Profile
802.1X Support
Guest VLAN
|
|
نوع پورت
|
Gigabit Ethernet
|
|
PoE
|
Yes
|
|
برند
|
D-link
|
