ویژگی های سخت افزاری دوربین
|
1/4Megapixel CMOS sensor
Built-in Infrared-Cut Removable (ICR) Filter module
5meter IR illumination distance
Minimum illumination: 0 lux with IR LED on
Built-in microphone and speaker
Digital zoom
Pan range: -170° to 170°
Tilt range: -25° to 95°
Focal length: 3.3 mm
Minimum object distance: 200 mm
Aperture: F2.2
: Angle of view
H) 70.4°)
V) 43°)
D) 84.6°)
|
|
اتصالات
|
802.11b/g/n wireless with WEP/WPA/WPA2 support
Operates over the 2.4 GHz frequency band
Single-band 1T1R mode supports a maximum data rate of
72.2 Mbps (PHY rate) using 20 MHz bandwidth
|
|
رابط کاربری
|
microSDHC card slot
Reset button
Direct button
(Power port (Micro-USB)
|
|
نشانگر LED
|
PWR LED: Link/Activity/Power
Cloud LED: Cloud/Direct Mode
|
|
ویژگی های تصویر
|
Configurable image size
Time stamp overlay
|
|
فرمت های فشرده سازی تصویر
|
H.264 format video compression
JPEG for still images
|
|
روزولوشن ویدیو
|
1280x 720 up to 30 fps
640x 352 up to 15 fps
|
|
فرمت صدا
|
AAC
ADPCM
5built-in lullabies
|
|
ویژگی های Baby Monitoring
|
Sound detection with adjustable sensitivity
Motion detection with adjustable sensitivity
Records snapshots and video to microSD when
motion or sound is detected
Temperature detection with configurable alert range
Sends notifications when sound or motion is detected
2way audio lets you listen and respond to your child
|
|
نرم افزار تلفن همراه
|
mydlink Baby Camera Monitor app available on the App Store® and Google Play™
Compatible with iPhone, iPad, or Android smartphones or tablets 2
|
|
پروتکل های شبکه
|
IPv4
ARP
TCP/IP
UDP
ICMP
DHCP client
HTTP
( HTTPS (for configuration)
UPnP port forwarding
RTP/RTSP/RTCP
|
|
امنیت
|
Administrator protection
Password authentication
HTTP authentication
|
|
منبع تغذیه
|
5V DC / 2 A, 50/60 Hz power adapter
Can be powered by an external USB battery with
at least 2 A output
|
|
ارتباط بی سیم
|
Wi-Fi
|
|
نوع دوربین
|
Indoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
