مشخصات سخت افزاری
|
1/3.2CMOS sensor
30metre IR illumination distance
Built-in infrared-cut removable (ICR) filter module
:Minimum illumination
0.5lux colour mode
0.1lux black and white mode
0lux black and white mode with IR LED on
Minimum object distance 0.3 m
12-2.8mm motorised zoom varifocal DC iris lens
Aperture F1.8
Angle of view
H) 29.47° to 72.84°)
V) 21.72° to 54.69°)
Shutter speed: 1/2.5 ~ 1/10,000
4x digital zoom
|
|
مشخصات تصویر
|
Configurable image size, quality, frame rate and bit rate
Time stamp and text overlays
Configurable motion detection windows
configurable privacy mask zones
Configurable shutter speed, brightness, saturation, contrast, and
sharpness, white balance, WDR, flip and mirror
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
H.264/MPEG-4 multicast streaming
|
|
رزولوشن ویدیو
|
16:9
1920×1080, 1280×720, 960 x 540 at up to 30 fps
4:3
2560×1920, 2048×1536, 1600×1200, 1280×960 at
up to 15 fps
|
|
فرمت صدا
|
AAC
G.711
|
|
رابط کاربری
|
1DI / 1 DO
Micro SD card slot
Built-in microphone
Audio input / output
(Video out (BNC
10/100BASE-TX Ethernet port with PoE
|
|
پروتکل های شبکه
|
IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP authentication
HTTPS encryption for web access
|
|
Event Management
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
مدیریت از راه دور
|
Take snapshots/video clips and save to local hard drive or NAS via web browser
Configuration interface accessible via web browser
|
|
منبع تغذیه
|
External power adapter: 12 V DC 1.5 A. 50/60 Hz
PoE: IEEE 802.3af Class 0
|
|
قابلیت های نرم افزار D-ViewCam™
|
Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
|
|
نوع
|
Bullet
|
|
محل نصب
|
Outdoor
|
|
برند
|
D-link
|
