| مشخصات سخت افزاری | 1/3Megapixel progressive CMOS sensor
:Minimum illumination
Color mode: 0.5 lux-
B/W mode (LEDs off): 0.1 lux-
B/W mode (LEDs on): 0 lux-
Minimum object distance 30 cm
Lens focal length: 1.7 mm
Aperture: F2.5
:(Angle of view (16:9
H) 180°)
V) 86°)
D) 180°)
Stand angle: -15° to 90° |
|---|
| مشخصات تصویر | Configurable image size, quality, frame rate, and bit rate
(Wide Dynamic Range (WDR
3D filtering
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, sharpness. |
|---|
| فرمت ویدیو | Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
H.264 multicast streaming |
|---|
| رزولوشن ویدیو | 16:9
1920x 1080 at up to 15 fps
1280x 720, 800 x 448, 640 x 360 at up to 30 fps |
|---|
| فرمت صدا | G.711 128 Kbps
AAC 32 Kbps |
|---|
| رابط کاربری | 802.11n/g wireless with WPA/WPA2 encryption
Operates on 2.4 GHz band
microSD card slot
Single-band 1T1R mode supports a maximum data
rate of 72.2 Mbps (PHY rate) using 20 MHz bandwidth |
|---|
| پروتکل های شبکه | IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP |
|---|
| امنیت | Administrator and user group protection
Password authentication
HTTP and RTSP authentication |
|---|
| Event Management | Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Sound level detection
Scheduled recording |
|---|
| منبع تغذیه | 5V DC, 1.2 A through external power adapter
Power adapter: 100 to 240 V AC, 50/60 Hz |
|---|
| ارتباط بی سیم | Wi-Fi |
|---|
| نوع دوربین | Indoor |
|---|
| PoE | Non PoE |
|---|
| برند | D-link |
|---|
