| استاندارد بی سیم | 802.11a/b/g/n 2.4/5.0 GHz |
|---|
| رابط کاربری | 10/100/1000Gigabit Ethernet |
|---|
| پورت کنسول | RJ-45 |
|---|
| آنتن | 2×2 MIMO embedded antenna with 4 external antenna connectors |
|---|
| فرکانس بی سیم | 802.11n: 2.4 to 2.497 GHz and 4.9 to 5.85 GHz
802.11b/g: 2.4 to 2.4835 GHz
802.11a: 5.15 to 5.35 GHz and 5.725 to 5.825 GHz |
|---|
| سرعت انتقال اطلاعات | :802.11n
(6.5Mbps-130 Mbps (20 MHz
(6.5MHz-300 Mbps (40 Mbps802.11a/g: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps
802.11b: 11, 5.5, 2 and 1 Mbps |
|---|
| مدیریت دستگاه | HTTP/HTTPS Web-based User Interface
SNMP, SSH, Telnet Command Line |
|---|
| SSID | 16SSID per frequency band, 32 SSID per AP
Station Isolation |
|---|
| امنیت بی سیم | WEP
Dynamic WEP
WPA Personal/ Enterprise
WPA2 Personal/ Enterprise |
|---|
| Detection & Prevention | Rogue and Valid AP Classification |
|---|
| تایید هویت | MAC Address Filtering
802.1x |
|---|
| منبع تغذیه | 12V 1 A |
|---|
| PoE | 48VDC +/- 10% |
|---|
| حالت Stand-Alone | WEP/WPA/WPA2 Security
Rogue AP Detection
Station Isolation
MAC Address Filtering
AP Load Balancing Setup
WDS
AP Clustering
QoS/WMM
Local Storage Configuration |
|---|
| Managed Mode(Managed by D-Link Wireless Switch/Wireless Controller) | Centralized Management
Centralized Firmware Dispatch
Visualized AP Management Tool
Auto-Power Adjustment
Dynamic Auto-Channel Selection
L2 Fast Roaming
L3 Fast Roaming
Captive Portal
WEP/WPA/WPA2 Security
Rogue AP Detection
Rogue AP Mitigation
WIDS
Station Isolation
MAC Address Filtering
AP Load Balancing Setup
WDS
QoS/WMM |
|---|
| سرعت | N800 و کمتر |
|---|
| فرکانس بی سیم | Dual Band (2.4GHz & 5GHz) |
|---|
| نوع پورت | Gigabit Ethernet |
|---|
| نوع | Indoor |
|---|
| نوع آنتن | External, Internal |
|---|
| برند | D-link |
|---|
